Model #: im

Color iMatch

Formulation Software

Color iMatch is a job-oriented color formulation solution for paint, plastics and textiles, enabling fast, accurate color analysis and colorant formulation for a variety of applications.

Color Management Software for Industrial Applications

Ensuring accurate, consistent color throughout a global supply chain can be challenging. With Color iMatch as an integral part of the color workflow, specifiers and suppliers alike can be assured that design intent is carried through to the final product. Using spectral matching, Color iMatch automatically determines the best colorant formula based on selected parameters, increasing formulation control and overall productivity and profitability.

Color iMatch is available in a variety of configurations to meet most, if not all, industrial color formulation needs, including:

  • Color iMatch Professional, a job-oriented solution for paint, plastics, or textile color formulation. This package enables quick, accurate color analysis and the capability to optimize every formula for cost and color accuracy. Available in four levels for specific formulation requirements. An integrated Quality Control module is included.
  • Color iMatch Management, a management configuration that has all of the functionality of Color iMatch Professional but does not connect to a spectrophotometer.
  • Color iMatch Satellite, a production-focused configuration of Color iMatch with the same functionality as the Professional version, both formulation and quality control, but without the ability to build or edit colorant databases.
  • Color iMatch Basic, a feature-reduced version of Color iMatch with the same functionality as the Professional version but without an integrated quality control module.
  • Color iMatch Online Edition, a server based solution that allows any number of locations to easily communicate and share color data. The Online configuration ensures centralized control and management yet provides easy access for all authorized users within the color network.


  •  Achieve one-hit matches practically every time with multi-flux based program, reducing turnaround time by half or more.
  •  Reduce color formulation time and costs with spectral matching.
  •  Improve operator efficiency with simple user interface and workflow prompts to guide the operator through the process.
  •  Manage color formulations across a distributed network with Color iMatch Satellite or Color iMatch Online Edition.
  •  Leverage included Color iQC software to save time and reduce waste from the laboratory through production.

Color iMatch is PantoneLIVE enabled. This means that users can retrieve the most up-to-date digital color standards from the cloud-based PantoneLIVE library in addition to or instead of using physical reference standards, which can be damaged, deteriorate over time, or be measured differently by operators in various locations using a variety of instruments.


Measurement Conditions Reflectance, Tranmission, Reflectance / Transmission, Over Light / Over Dark, SCI / SCE
Color Differences FMCII, CIE DL*, Da*, Db*, CIE DL*, DC*, DH*, Hunter DL, Da, Db, All Attributes of CIELab, CIELch or HunterLab, CMC (l:c), CIE2000 (l:c:h)
Color Spaces CIE L*a*b*, CIE L*C*h*, Hunter Lab, CIE (XYZxy)
Illuminants D50, D55, D65, D75, F2, F7, F11, C, A, Horizon, TL84, Ultralume 3000
Observers 2 degree,10 degree
Standard Indices Whiteness [ASTM E313, CIE, GANZ, Berger, Stensby, Taube, Tappi], Yellowness [ASTM E313, D1925], Opacity [Contrast Ratio, Tappi], Strength [SWL, Summed, Weighted Sum], Haze, Munsell Notation, Orange Juice, Gloss [ASTM E429, Gloss60], Grey Scale [ISO 105, Staining, Color Change], Metamerism, Color Constancy Index, APHA, Gardner Color Index, ASTM Color Index, Saybolt Color Index, AATCC TM203 Light Blocking Index, DIN55979 Blackness Index, G7 Substrate Compensation
Configuration Options Basic, Professional, Management, Satellite, Online Editions
Databases MS Access, MS SQL Server
Experience Level Beginner to Advanced
Import/Export Format CxF, QTX, JB5, MIF
Languages Supported English, French, German, Spanish, Italian, Portuguese, Japanese, Chinese
Supported Devices eXact, eXact Scan, eXact XP, CI4200, CI52, CI62, CI64, 962, 964, Color i5, Color i7, CE-7000A, CI7600, CI7800, SP62, SP64
User Experience Configurable
Industry Standards See Standard Indices
Ink Wells / Ink Units No
Mobile Device Compatibility No
NetProfiler Support Yes
PantoneLIVE Support Yes
Pass / Fail Yes
Sample Preview Yes
What's Included? Installation CD with Instructions
Android No
Apple iOS No
Windows Win 7, Win 10
Available Disk Space 5 GB - 100 GB
Connectivity USB-Port
Display Resolution 1024 x 768
Internet Connection Yes, for PantoneLIVE
Memory 2GB
Number of Displays Supported per Workstation 1
Optical Drive Yes
Processor Core 2 Duo, 2 G
Security Install Only
Compatible Android Devices None
Compatible iOS Devices None
