Model #: ci62-xr

Ci62 Spectrophotometer

Production QC Spectrophotometer

The Ci62 portable sphere spectrophotometer is a high-performance instrument uniquely suited for ensuring accurate color on reflective surfaces, including applications with textured materials or printing on metal substrates.

Accurate Color on Complex Materials

Customers demand consistent color, yet to establish a more compelling presence in a crowded marketplace, they are using more metallics, special effect finishes and textures to help their products stand out. These materials and finishes add value to products and packaging. But they are also more expensive, making consistent color monitoring and an effective quality control program a must in order to reduce waste and rework.

With a choice of 4mm (Ci62S) or 8mm (Ci62) measurement aperture and the ability to output simultaneous SPIN, SPEX and Correlated Gloss measurements, the Ci62 handheld sphere spectrophotometer is one of the most capable and flexible measurement instruments in the marketplace today. A remote measurement trigger allows operators to initiate hands-free measurement.  When paired with Color iQC software, the Ci62 is the ideal mid-range solution for organizations in the textile, paint & coatings, plastics and packaging industries who seek improved quality control and reduced cycle time and rework.

Benefits:

  • Accurately measure reflective or uneven surfaces on a wide variety of products and packaging types.
  • Ensure a color quality audit trail across multiple devices and locations to ensure consistent color and brand integrity in a supply chain.
  • Access up to 4,000 reference samples stored in the device for fast access to existing data.
  • Increase instrument up-time with optional dual-bay charging to use the Ci62 while charging the second battery.
  • Remotely ascertain and optimize. With NetProfiler, users can apply corrections to improve measurement performance, with or without a PC connection.
The X-Rite Ci62 sphere spectrophotometer is the ideal mid-range solution for organizations with color-critical needs. With its embedded X-Rite NetProfiler, the Ci62 provides a complete track and trace process for consistent measurement across multiple devices and locations, with a 0.20 average delta E inter-instrument agreement.

Need More Information?

Specifications

Short Term Repeatability - White .05 ΔE*ab on white ceramic
Measurement Geometry d/8°
Inter-Instrument Agreement 0.20 ΔE*ab avg.
Illumination Spot Size 20mm or 14mm or 6.5mm
Lamp Life Approx. 500,000 measurements
Light Source Gas-filled tungsten lamp
Measurement Cycle Time ≈ 2 seconds
Measurement Spot 14mm or 8mm or 4mm
Measurement Time ≈ 2 seconds
Photometric Range 0 to 200%
Photometric Resolution 0.01%
Spectral Analyzer Blue-enhanced silicon photodiodes
Spectral Interval 10nm
Spectral Range 400nm-700nm
Spectral Reporting 10nm
Color Differences [√/X], Δecmc, Δlab,  ΔE00, Δreflectance,  ΔE94, ΔXYZ, ΔL*a*b*, ΔYxy, , ΔL*C*h°, ΔL*u*v*, Verbal Difference
Color Spaces Lab, L*a*b*, Reflectance,  L*C*h°, Munsell Notation, XYZ, Yxy, L*u*v*
Illuminants A, C, D50, D65, F2, F7, F11 & F12
Observers 2° & 10°
Standard Indices [√/X], YI1925, WI Taube, ΔWI73, Reflectance, WI98, MI, Δreflectance,  ΔWI Berger, WI73, MI6172, ΔYI98, ΔWI Hunter, Gray Scale, WI Berger, Gloss, ΔYI73, ΔWI Stensby, YI98, WI Hunter, ΔYI1925, ΔWI Taube, YI73, WI Stensby, ΔWI98, Averging, 555 Shade Sort
Reflectance Aperture(s) 1
Humidity 5% to 85%, non-condensing
Operating Temperature Range 50° to 104°F (10° to 40°C)
Storage Temperature Range '-4° to 122°F (-20° to 50°C)
Dimensions (length, width, height) 21.3 cm 9.1 cm 10.9 cm
Weight 1.06 kg
Package Dimensions (length, width, height)  51cm, 20cm, 41cm
Shipped Weight '7kg
Communication Interface USB 2.0, Bluetooth*
Import/Export Format CSV
Instrument Display Backlit Color Graphic LCD
Languages Supported English, German, French, Spanish, Italian, Portuguese, Chinese Simplified, Chinese Traditional, Korean, and Japanese
Software Development Kit XDS4
Battery Li-ion
Voltage
100-240VAC 50/60Hz,
12VDC @ 2.5A
Sample/Measurement 4000
Standards 1000
Calibration White and Zero
Embedded NetProfiler Support Yes
NetProfiler Support Embedded
PantoneLIVE Support Via software
Pass / Fail Yes
Sample Preview Targeting window
Transform Support Embedded
Warranty 12 months
What's Included? Instrument with white calibration standard, black trap, green standard, manual(CD), AC adapter, USB cable, carry case
