モデル番号: VS3200
非接触イメージング分光測色計 MetaVue™ VS3200(メタビュー・ブイエス 3200)
品質管理&調色測定
非接触イメージング分光測色計 MetaVue™ VS3200 は、濡れた状態、乾燥した状態に関わらず、プラスチック、化粧品、小型、変形サイズなど、多様なサンプルを正確に測定します。.
業界トップクラスの非接触式測定機能
塗装、プラスチック、化粧品などの工業用製品を正確かつ一貫して測定することは非常に重要です。この万能な非接触式イメージング分光測色計は、調色作業、生産色の検証、品質管理をスピードアップし、無駄の削減とサイクル時間を短縮します。プラスチック部品や液体塗装など、様々な用途に対応します。これは、頻繁に色変更を要する環境に重要な点です。
非接触式のVS3200イメージング分光測色計は、優れた万能性と測色精度を提供。ラボと品質管理における測定作業を簡素化します。MetaVueの非接触イメージング測定機能は、従来測色が難しい小型、非平面、液体、粉体、ペースト状やゼリー状のサンプルにも対応します。追加情報はこちらをご覧ください。
特長:
- 2mm~12mmのアパーチャーサイズで、多様なサンプルに対応。
- 測定ターゲット範囲を的確に判断するデジタル機能。
- 画像サンプルを測定記録と共に保存。データをいつでも参照可能。
- 既存のワークフローに対応し、新規データベースは作成不要。X-Rite VS450 と 964 とのデータ互換性を提供。
非接触イメージング分光測色計MetaVue VS3200は直感的に操作できる装置で、サンプルの測定位置に合わせて伸縮自在なポジショニング機能が付いています。クリーニングも簡単です。エックスライトの調色/品質管理ソフトウェアColor iMatch および品質管理ソフトウェアColor iQCと併用し、迅速かつ確実な調色と、効率的な品質管理を実現します。柔軟性/順応性が高いアクセサリーには次が含まれます。1. 交換可能な引き出しトレイが備わった測定専用スタンド。装置を測定台から約8cm上にセットし、粉体、液体、ペースト状のサンプルを容易に測定。2. 多様な厚さのサンプルを正確に測定する調整用スタンド。2. 非接触式の「MetaVue VS3200」を、サンプルアームの付いたベンチトップ式装置として使用可能なベンチトップスタンド。プラスチック部品などを測定する際に利便性を提供。グリーンタイルの検証と校正証明書が付属。NetProfiler ソフトウェア(オプション製品)は、装置のパフォーマンスを検証および最適化します。
仕様
測定アパーチャー | 2mm ~ 12mm |
---|---|
インターフェース | USB |
製品寸法(奥行/幅/高さ) | 幅 25 cm x 高さ 18 cm x 奥行 18 cm |
湿度 | 0% ~ 85%(結露なし) |
照明スポットサイズ | 14 mm |
測定時のサンプル接触 | 非接触式 |
規格 | ASTM D2244, ASTM E179, ASTM E308, ASTM E1164, CIE 15, DIN 5033 Teil 7, DIN 5036, DIN 6174, ISO 7724, JIS Z 8722 |
装置ディスプレイ | ディスプレイなし |
器差 | 0.15 ΔE*ab 平均 |
光源 | フルスペクトル LED |
測定サイクルタイム | < 8 秒 |
光学幾何条件 | 45°/0° イメージング分光測色計 |
測定スポット | 2mm ~ 12mm |
測定距離 | Up to 3.1mm |
梱包サイズ(奥行/幅/高さ) | 幅 39 cm x 高さ 29 cm x 奥行 29 cm |
光学分解能 | 10nm 間隔 |
反射測定用アパーチャー | 2mm ~ 12mm |
短期繰り返し精度 - ホワイト | 0.025 ΔE*ab RMS |
ソフトウェア開発キット | Yes |
分光分析 | DRS フィルター軸 |
分光範囲 | 400nm ~ 700nm @ 10nm 間隔 |
分光レポート出力 | 400nm ~ 700nm @ 10nm 間隔 |
ステータスパネル | 三色 LED |
保存温度範囲 | -20°C ~ 70°C |
本体カラー | ブラック&シルバー |
電圧 | ユニバーサル電源、100~240 VAC |
重量 | 2.5 kg |
