Model #: erx130
The ERX130 is a non-contact, inline spectrophotometer for reflectance measurement with coaxial geometry. The large measurement distance and huge measurement spot are ideal for color measurement of structured and small patterned samples in industrial applications for early identification and correction of disturbances.
ERX130 Automated Inline Color Measurement Delivers Early Warning of Color Shifts
During manufacturing, color shifts can be costly, resulting in waste, rework and delayed time to market. Using high quality inline color measurement instruments provides operators with the real-time color information required to avoid costly production line errors.
Designed to meet the needs of a variety of industrial applications, the ERX130 measures a wide range of materials and is able to operate in even the harshest environments. This automated inline quality control system provides non-contact measurement and continuous reporting. It is easy to operate and offers comparisons to specific standards or absolute measurements.
When used with ESWin QC software, the ERX130 enables accurate color adjustments that improve manufacturing output and reduce waste due to color drift.
- Measures and evaluates color deviation so operators can make immediate corrections without stopping production.
- Measures the product at a distance of 300 mm (11.8”).
- Using a large 90 mm (3.5”) measurement area, delivers a good average of the measured surface.
- Measures a full range of materials, including textured, finely patterned, gloss and for products such as vinyl, textiles, food, pigments, paints, plasters, films and bulk goods like powders or sands.
- External calibration is only necessary every 4 weeks for maximum instrument uptime.
|Short Term Repeatability - White||dL*, da*, db* < 0.03|
|Measurement Geometry||coaxial to the illumination (= 45° to the gloss axes)|
|Measurement Working Distance||300 mm|
