Model #: 361t

361T

The 361T Tabletop Transmission Densitometer from X-Rite is ideal for linearizing imagesetters, adjust exposure and performing processor quality control in film processing.
Questions?  1.800.248.9748

Accurately Measure Density on Film

The X-Rite 361T Tabletop Transmission Densitometer is ideal for film-based workflows, and is used to measure both density (up to 6.0D) and dot area. Use the 361T to linearize imagesetters, adjust exposure, perform processor quality control, and verify duplicated or contacted films. UV mode measures film base fog and evaluates diazo films.

Benefits:

  • Standard apertures of 1mm, 2mm and 3mm offer flexibility in measurement areas.
  • Measure both negative and positive percent dot area.
  • Includes both Ortho and UV densitometer responses.
  • Includes cable interface for transmitting dot area readings to computers.

Specifications

Short Term Repeatability - Density
Ortho,Visual (2 mm and 3 mm aperture):
 0.0 D to 5.0 D: ± 0.01 D
 5.0 D to 5.5 D: ± 2 %
 5.5 D to 6.0 D: ± 3 %

Ortho,Visual (1 mm aperture):
 0.0 D to 4.5 D: ± 0.01 D
4.5 D to 5.0 D: ± 1 %

UV (3 mm aperture):
 0.0 D to 3.5 D: ± 0.01 D
3.5 D to 4.0 D: ± 1 %
Measurement Geometry Per ANSI PH 2.19, ISO 5/2
Inter-Instrument Agreement 0.0 D - 5.0 D: ± 0.02 D, ± 2 %
Linearity
Ortho,Visual (2mm and 3mm aperture):
0.0 D to 5.0 D: ± 0.02 D
5.0 D to 5.5 D: ± 1%
5.5 D to 6.0 D: ± 2%

Ortho,Visual (1mm aperture):
 0.0 D to 4.5 D: ± 0.02 D
4.5 D to 5.0 D: ± 1 %

UV (3mm aperture):
0.0 D to 3.5 D: ± 0.02 D
3.5 D to 4.0 D: ± 1 %
Aperture
1mm, 2mm and 3mm
(0.5mm optional)
Humidity ≤ 76%
Operating Temperature Range
10°C to 40°C
50°F to 104°F
Storage Temperature Range
'-20° to 50°C
-4° to 122°F
Dimensions (length, width, height)
43.5 cm x 33.0 cm x 15.2 cm
17.1" x 13.1" x 6.0"
Weight
8.63 kg
19 lbs.
Shipped Weight
17.5 kg
7.95 lbs.
Communication Interface RS-232 serial interface
Instrument Display 8 character LCD
Voltage
90 - 130 VAC 50 - 60 Hz
120 - 260 VAC 50 - 60 Hz
Warm Up Time
2 minutes
5 minutes (UV)
Wattage 80 VA max.
Density Range
0.0 D to > 6.0 D
0 % to 100 %
Density Standards X-Rite Visual, X-Rite Ortho, X-Rite UV
Industry Standards  ISO 5-2, ANSI PH2.19
Warranty 1 year
